C++项目 | 集群聊天服务器 | 客户端好友功能、群组功能开发以及退出功能实现

1.服务器支持的命令

// "help" command handler
void help(int fd = 0, string str = "");
// "chat" command handler
void chat(int, string);
// "addfriend" command handler
void addfriend(int, string);
// "creategroup" command handler
void creategroup(int, string);
// "addgroup" command handler
void addgroup(int, string);
// "groupchat" command handler
void groupchat(int, string);
// "loginout" command handler
void loginout(int, string);

// 系统支持的客户端命令列表
unordered_map<string, string> commandMap = {
    {"help", "显示所有支持的命令，格式help"},
    {"chat", "一对一聊天，格式chat:friendid:message"},
    {"addfriend", "添加好友，格式addfriend:friendid"},
    {"creategroup", "创建群组，格式creategroup:groupname:groupdesc"},
    {"addgroup", "加入群组，格式addgroup:groupid"},
    {"groupchat", "群聊，格式groupchat:groupid:message"},
    {"loginout", "注销，格式loginout"}};

// 注册系统支持的客户端命令处理
unordered_map<string, function<void(int, string)>> commandHandlerMap = {
    {"help", help},
    {"chat", chat},
    {"addfriend", addfriend},
    {"creategroup", creategroup},
    {"addgroup", addgroup},
    {"groupchat", groupchat},
    {"loginout", loginout}
};

2.好友功能相关

实现chat函数时遇到的问题：

json解析时出现问题，本来应该接收到一个int结果却是null

是因为发送方和接受方的json格式没有对应

聊天业务中发送方的json中是to，而接收方json中是toid，导致出现解析问题

// "help" command handler
void help(int, string)
{
    cout << "show command list >>> " << endl;
    for (auto &p : commandMap)
    {
        cout << p.first << " : " << p.second << endl;
    }
    cout << endl;
}
// "addfriend" command handler
void addfriend(int clientfd, string str)
{
    int friendid = atoi(str.c_str());
    json js;
    js["msgid"] = ADD_FRIEND_MSG;
    js["id"] = g_currentUser.getId();
    js["friendid"] = friendid;
    string buffer = js.dump();

    int len = send(clientfd, buffer.c_str(), strlen(buffer.c_str()) + 1, 0);
    if (-1 == len)
    {
        cerr << "send addfriend msg error -> " << buffer << endl;
    }
}

// "chat" command handler
void chat(int clientfd, string str)
{
    int idx = str.find(":"); // friendid:message
    if (-1 == idx)
    {
        cerr << "chat command invalid!" << endl;
        return;
    }

    int friendid = atoi(str.substr(0, idx).c_str());
    string message = str.substr(idx + 1, str.size() - idx);

    json js;
    js["msgid"] = ONE_CHAT_MSG;
    js["id"] = g_currentUser.getId();
    js["name"] = g_currentUser.getName();
    js["toid"] = friendid;
    js["msg"] = message;
    js["time"] = getCurrentTime();
    string buffer = js.dump();

    int len = send(clientfd, buffer.c_str(), strlen(buffer.c_str()) + 1, 0);
    if (-1 == len)
    {
        cerr << "send chat msg error -> " << buffer << endl;
    }
}

3.群组功能相关


// "creategroup" command handler  groupname:groupdesc
void creategroup(int clientfd, string str)
{
    int idx = str.find(":");
    if (-1 == idx)
    {
        cerr << "creategroup command invalid!" << endl;
        return;
    }

    string groupname = str.substr(0, idx);
    string groupdesc = str.substr(idx + 1, str.size() - idx);

    json js;
    js["msgid"] = CREATE_GROUP_MSG;
    js["id"] = g_currentUser.getId();
    js["groupname"] = groupname;
    js["groupdesc"] = groupdesc;
    string buffer = js.dump();

    int len = send(clientfd, buffer.c_str(), strlen(buffer.c_str()) + 1, 0);
    if (-1 == len)
    {
        cerr << "send creategroup msg error -> " << buffer << endl;
    }
}
// "addgroup" command handler
void addgroup(int clientfd, string str)
{
    int groupid = atoi(str.c_str());
    json js;
    js["msgid"] = ADD_GROUP_MSG;
    js["id"] = g_currentUser.getId();
    js["groupid"] = groupid;
    string buffer = js.dump();

    int len = send(clientfd, buffer.c_str(), strlen(buffer.c_str()) + 1, 0);
    if (-1 == len)
    {
        cerr << "send addgroup msg error -> " << buffer << endl;
    }
}

// "groupchat" command handler   groupid:message
void groupchat(int clientfd, string str)
{
    int idx = str.find(":");
    if (-1 == idx)
    {
        cerr << "groupchat command invalid!" << endl;
        return;
    }

    int groupid = atoi(str.substr(0, idx).c_str());
    string message = str.substr(idx + 1, str.size() - idx);

    json js;
    js["msgid"] = GROUP_CHAT_MSG;
    js["id"] = g_currentUser.getId();
    js["name"] = g_currentUser.getName();
    js["groupid"] = groupid;
    js["msg"] = message;
    js["time"] = getCurrentTime();
    string buffer = js.dump();

    int len = send(clientfd, buffer.c_str(), strlen(buffer.c_str()) + 1, 0);
    if (-1 == len)
    {
        cerr << "send groupchat msg error -> " << buffer << endl;
    }
}

4.注销功能

加入了全局变量isMainMenuRunning表示用户是否在线，退出登录后就变为false，在线就是true

// "loginout" command handler
void loginout(int clientfd, string)
{
    json js;
    js["msgid"] = LOGINOUT_MSG;
    js["id"] = g_currentUser.getId();
    string buffer = js.dump();

    int len = send(clientfd, buffer.c_str(), strlen(buffer.c_str()) + 1, 0);
    if (-1 == len)
    {
        cerr << "send loginout msg error -> " << buffer << endl;
    }
    else
    {
        //代表用户退出登录了
        isMainMenuRunning=false;
    }
}

ChatService.cpp

记得要先绑定

//处理注销业务
void ChatService::loginout(const TcpConnectionPtr& conn,json &js,Timestamp time)
{
    int userid=js["id"].get<int>();

    {
        lock_guard<mutex> lock(_connMutex);
        auto it=_userConnMap.find(userid);
        if(it!=_userConnMap.end())
        {
            _userConnMap.erase(it);
        }
    }

    //更新用户状态信息
    User user(userid,",","offline");
    _userModel.updateState(user);
}

5.完整的客户端代码

#include"json.hpp"
#include<iostream>
#include<thread>
#include<string>
#include<vector>
#include<chrono>
#include<ctime>
using namespace std;

using json=nlohmann::json;

#include<unistd.h>
#include<sys/socket.h>
#include<sys/types.h>
#include<netinet/in.h>
#include<arpa/inet.h>

#include"group.hpp"
#include"user.hpp"
#include"public.hpp"

//控制主菜单页面程序 用户输入loginout要退出的时候改为false
bool isMainMenuRunning=false;

//记录当前系统登录的用户信息
User g_currentUser;

//记录当前登录用户的好友列表信息
vector<User> g_currentUserFriendList;

//记录当前登录用户的群组列表信息
vector<Group> g_currentUserGroupList;

//显示当前登录成功用户的基本信息
void showCurrentUserData();

//接收线程
void readTaskHandler(int clientfd);

//获取系统时间 （聊天信息需要添加时间信息）
string getCurrentTime();

//主页面程序
void mainMenu(int clientfd);

//聊天客户端程序实现，main线程用作发送消息的线程，子线程用作接收消息的线程
int main(int argc,char **argv)
{
    if(argc<3)
    {
        cerr<<"command invalid!example: ./ChatClient 127.0.0.1 6000"<<endl;
        exit(-1);
    }

    //解析通过命令行参数传递的ip和port
    char *ip=argv[1];
    uint16_t port=atoi(argv[2]);

    //创建client端的socket
    int clientfd=socket(AF_INET,SOCK_STREAM,0);
    if(-1==clientfd)
    {
        cerr<<"socket create error"<<endl;
        exit(-1);
    }

    //填写client需要连接的server信息ip+port
    sockaddr_in server;
    memset(&server,0,sizeof(sockaddr_in));

    server.sin_family=AF_INET;
    server.sin_port=htons(port);
    server.sin_addr.s_addr=inet_addr(ip);

    //client和server连接
    if(-1==connect(clientfd,(sockaddr *)&server,sizeof(sockaddr_in)))
    {
        cerr<<"connect server error"<<endl;
        close(clientfd);
        exit(-1);
    }

    //main线程用于接收用户输入负责发送数据
    for(;;)
    {
        //显示首页页面菜单 登录、注册、退出
        cout<<"======================="<<endl;
        cout<<"1.login"<<endl;
        cout<<"2.register"<<endl;
        cout<<"3.quit"<<endl;
        cout<<"======================="<<endl;
        cout<<"choice:";
        int choice = 0;
        cin>>choice;
        cin.get();//读掉缓冲区残留的回车

        switch(choice)
        {
            case 1://login业务
            {
                int id=0;
                char pwd[50]={0};
                cout<<"userid:";
                cin>>id;
                cin.get();//读掉缓冲区残留的回车
                cout<<"userpassword:";
                cin.getline(pwd,50);

                json js;
                js["msgid"]=LOGIN_MSG;
                js["id"]=id;
                js["password"]=pwd;
                string request=js.dump();

                int len=send(clientfd,request.c_str(),strlen(request.c_str())+1,0);
                if(len==-1)
                {
                    cerr<<"send login msg error:"<<request<<endl;
                }
                else
                {
                    char buffer[1024]={0};
                    len=recv(clientfd,buffer,1024,0);
                    if(len==-1)
                    {
                        cerr<<"recv login msg error:"<<request<<endl;
                    }
                    else
                    {
                        json responsejs=json::parse(buffer);
                        if(0!=responsejs["errno"].get<int>())
                        {
                            cerr<<responsejs["errmsg"]<<endl;
                        }
                        else//登陆成功
                        {
                            //记录当前用户的id和name
                            g_currentUser.setId(responsejs["id"].get<int>());
                            g_currentUser.setName(responsejs["name"]);

                            //记录当前的好友列表
                            //如果这个人有好友
                            if(responsejs.contains("friends"))
                            {
                                //初始化
                                g_currentUserFriendList.clear();

                                vector<string> vec=responsejs["friends"];
                                for(string &str:vec)
                                {
                                    json js=json::parse(str);
                                    User user;
                                    user.setId(js["id"].get<int>());
                                    user.setName(js["name"]);
                                    user.setState(js["state"]);
                                    g_currentUserFriendList.push_back(user);
                                }
                            }

                            //记录当前用户的群组列表信息
                            if(responsejs.contains("groups"))
                            {
                                //初始化 出去原来已经拉入过来的数据
                                g_currentUserGroupList.clear();

                                vector<string> vec1 = responsejs["groups"];
                                for (string &groupstr : vec1)
                                {
                                    json grpjs = json :: parse(groupstr);
                                    Group group;
                                    group.setId(grpjs["id"].get<int>());
                                    group.setName(grpjs["groupname"]);
                                    group.setDesc(grpjs["groupdesc"]);
                                    vector<string> vec2 = grpjs["users"];
                                    for (string &userstr : vec2)
                                    {
                                        GroupUser user;
                                        json js = json :: parse(userstr);
                                        user.setId(js["id"].get<int>());
                                        user.setName(js["name"]);
                                        user.setState(js["state"]);
                                        user.setRole(js["role"]);
                                        group.getUsers().push_back(user);
                                    }
                                    g_currentUserGroupList.push_back(group);
                                }
                            }

                            //显示登录用户的基本信息
                            showCurrentUserData();

                            //显示当前用户的离线消息 个人聊天信息或者群组消息
                            if(responsejs.contains("offlinemsg"))
                            {
                                vector<string> vec=responsejs["offlinemsg"];
                                for(string &str:vec)
                                {
                                    json js=json::parse(str);
                                    int msgtype=js["msgid"].get<int>();
                                    if (ONE_CHAT_MSG == msgtype)
                                    {
                                        cout << js["time"].get<string>() << " [" << js["id"] << "]" << js["name"].get<string>()
                                        << " said: " << js["msg"].get<string>() << endl;

                                    }
                                    if (GROUP_CHAT_MSG == msgtype)
                                    {
                                        cout << "群消息[" << js["groupid"] << "]:" << js["time"].get<string>() << " [" << js["id"] << "]" << js["name"].get<string>()
                                             << " said: " << js["msg"].get<string>() << endl;
                                    }
                                }
                            }
                            //登陆成功，启动接收线程负责接收数据
                            static int readthreadNumber=0;
                            if(readthreadNumber==0)
                            {
                                std::thread readTask(readTaskHandler,clientfd);
                                readTask.detach();
                                readthreadNumber++;
                            }
                            //进入主菜单页面
                            isMainMenuRunning=true;
                            mainMenu(clientfd);
                        }
                    }
                }
            }
            break;
            case 2://register业务
            {
                char name[50]={0};
                char pwd[50]={0};
                cout<<"usernam:";
                cin.getline(name,50);
                cout<<"userpassword:";
                cin.getline(pwd,50);

                json js;
                js["msgid"]=REG_MSG;
                js["name"]=name;
                js["password"]=pwd;
                string request=js.dump();

                int len=send(clientfd,request.c_str(),strlen(request.c_str())+1,0);
                if(len==-1)
                {
                    cerr<<"send reg msg error:"<<request<<endl;
                }
                else
                {
                    char buffer[1024]={0};
                    len=recv(clientfd,buffer,1024,0);
                    if(-1==len)
                    {
                        cerr<<"recv reg response error"<<endl;
                    }
                    else
                    {
                        json responsejs=json::parse(buffer);
                        if(0!=responsejs["errno"].get<int>())//注册失败
                        {
                            cerr<<name<<"is already exist,register error!"<<endl;
                        }
                        else//注册成功
                        {
                            cout<<name<<"register success,userid is "<<responsejs["id"]<<",do not forget it!"<<endl;
                        }
                    }
                }
            }
            break;
            case 3://quit业务
                close(clientfd);
                exit(0);
            default:
                cerr<<"invalid input!"<<endl;
                break;
        }
    }
    return 0;
}

//显示当前登录成功用户的基本信息
void showCurrentUserData()
{
    cout<<"==================login user=================="<<endl;
    cout<<"current login user id:"<<g_currentUser.getId()<<" name:"<<g_currentUser.getName()<<endl;
    cout<<"------------------friend list-----------------"<<endl;
    if(!g_currentUserFriendList.empty())
    {
        for(User &user:g_currentUserFriendList)
        {
            cout<<user.getId()<<" "<<user.getName()<<" "<<user.getState()<<endl;
        }
    }
    cout<<"------------------group list------------------"<<endl;
    if(!g_currentUserGroupList.empty())
    {
        for(Group &group:g_currentUserGroupList)
        {
            cout<<group.getId()<<" "<<group.getName()<<" "<<group.getDesc()<<endl;
            for(GroupUser &user:group.getUsers())
            {
                cout<<user.getId()<<" "<<user.getName()<<" "<<user.getState()<<" "<<user.getRole()<<endl;
            }
        }
    }
    cout<<"=============================================="<<endl;
}

// "help" command handler
void help(int fd = 0, string str = "");
// "chat" command handler
void chat(int, string);
// "addfriend" command handler
void addfriend(int, string);
// "creategroup" command handler
void creategroup(int, string);
// "addgroup" command handler
void addgroup(int, string);
// "groupchat" command handler
void groupchat(int, string);
// "loginout" command handler
void loginout(int, string);

// 系统支持的客户端命令列表
unordered_map<string, string> commandMap = {
    {"help", "显示所有支持的命令，格式help"},
    {"chat", "一对一聊天，格式chat:friendid:message"},
    {"addfriend", "添加好友，格式addfriend:friendid"},
    {"creategroup", "创建群组，格式creategroup:groupname:groupdesc"},
    {"addgroup", "加入群组，格式addgroup:groupid"},
    {"groupchat", "群聊，格式groupchat:groupid:message"},
    {"loginout", "注销，格式loginout"}};

// 注册系统支持的客户端命令处理
unordered_map<string, function<void(int, string)>> commandHandlerMap = {
    {"help", help},
    {"chat", chat},
    {"addfriend", addfriend},
    {"creategroup", creategroup},
    {"addgroup", addgroup},
    {"groupchat", groupchat},
    {"loginout", loginout}
};

//获取系统时间 （聊天信息需要添加时间信息）
string getCurrentTime()
{
    auto tt = std::chrono::system_clock::to_time_t(std::chrono::system_clock::now());
    struct tm *ptm = localtime(&tt);
    char date[60] = {0};
    sprintf(date, "%d-%02d-%02d %02d:%02d:%02d",
            (int)ptm->tm_year + 1900, (int)ptm->tm_mon + 1, (int)ptm->tm_mday,
            (int)ptm->tm_hour, (int)ptm->tm_min, (int)ptm->tm_sec);
    return std::string(date);
}

//主页面程序
void mainMenu(int clientfd)
{
    help();

    char buffer[1024] = {0};
    while(isMainMenuRunning)
    {
        cin.getline(buffer, 1024);
        string commandbuf(buffer);
        string command; // 存储命令
        int idx = commandbuf.find(":");
        if (-1 == idx)
        {
            command = commandbuf;
        }
        else
        {
            command = commandbuf.substr(0, idx);
        }
        auto it = commandHandlerMap.find(command);
        if (it == commandHandlerMap.end())
        {
            cerr << "invalid input command!" << endl;
            continue;
        }

        // 调用相应命令的事件处理回调，mainMenu对修改封闭，添加新功能不需要修改该函数
        it->second(clientfd, commandbuf.substr(idx + 1, commandbuf.size() - idx)); // 调用命令处理方法
    }
}

// "help" command handler
void help(int, string)
{
    cout << "show command list >>> " << endl;
    for (auto &p : commandMap)
    {
        cout << p.first << " : " << p.second << endl;
    }
    cout << endl;
}
// "addfriend" command handler
void addfriend(int clientfd, string str)
{
    int friendid = atoi(str.c_str());
    json js;
    js["msgid"] = ADD_FRIEND_MSG;
    js["id"] = g_currentUser.getId();
    js["friendid"] = friendid;
    string buffer = js.dump();

    int len = send(clientfd, buffer.c_str(), strlen(buffer.c_str()) + 1, 0);
    if (-1 == len)
    {
        cerr << "send addfriend msg error -> " << buffer << endl;
    }
}

// "chat" command handler
void chat(int clientfd, string str)
{
    int idx = str.find(":"); // friendid:message
    if (-1 == idx)
    {
        cerr << "chat command invalid!" << endl;
        return;
    }

    int friendid = atoi(str.substr(0, idx).c_str());
    string message = str.substr(idx + 1, str.size() - idx);

    json js;
    js["msgid"] = ONE_CHAT_MSG;
    js["id"] = g_currentUser.getId();
    js["name"] = g_currentUser.getName();
    js["toid"] = friendid;
    js["msg"] = message;
    js["time"] = getCurrentTime();
    string buffer = js.dump();

    int len = send(clientfd, buffer.c_str(), strlen(buffer.c_str()) + 1, 0);
    if (-1 == len)
    {
        cerr << "send chat msg error -> " << buffer << endl;
    }
}

// "creategroup" command handler  groupname:groupdesc
void creategroup(int clientfd, string str)
{
    int idx = str.find(":");
    if (-1 == idx)
    {
        cerr << "creategroup command invalid!" << endl;
        return;
    }

    string groupname = str.substr(0, idx);
    string groupdesc = str.substr(idx + 1, str.size() - idx);

    json js;
    js["msgid"] = CREATE_GROUP_MSG;
    js["id"] = g_currentUser.getId();
    js["groupname"] = groupname;
    js["groupdesc"] = groupdesc;
    string buffer = js.dump();

    int len = send(clientfd, buffer.c_str(), strlen(buffer.c_str()) + 1, 0);
    if (-1 == len)
    {
        cerr << "send creategroup msg error -> " << buffer << endl;
    }
}
// "addgroup" command handler
void addgroup(int clientfd, string str)
{
    int groupid = atoi(str.c_str());
    json js;
    js["msgid"] = ADD_GROUP_MSG;
    js["id"] = g_currentUser.getId();
    js["groupid"] = groupid;
    string buffer = js.dump();

    int len = send(clientfd, buffer.c_str(), strlen(buffer.c_str()) + 1, 0);
    if (-1 == len)
    {
        cerr << "send addgroup msg error -> " << buffer << endl;
    }
}

// "groupchat" command handler   groupid:message
void groupchat(int clientfd, string str)
{
    int idx = str.find(":");
    if (-1 == idx)
    {
        cerr << "groupchat command invalid!" << endl;
        return;
    }

    int groupid = atoi(str.substr(0, idx).c_str());
    string message = str.substr(idx + 1, str.size() - idx);

    json js;
    js["msgid"] = GROUP_CHAT_MSG;
    js["id"] = g_currentUser.getId();
    js["name"] = g_currentUser.getName();
    js["groupid"] = groupid;
    js["msg"] = message;
    js["time"] = getCurrentTime();
    string buffer = js.dump();

    int len = send(clientfd, buffer.c_str(), strlen(buffer.c_str()) + 1, 0);
    if (-1 == len)
    {
        cerr << "send groupchat msg error -> " << buffer << endl;
    }
}

// "loginout" command handler
void loginout(int clientfd, string)
{
    json js;
    js["msgid"] = LOGINOUT_MSG;
    js["id"] = g_currentUser.getId();
    string buffer = js.dump();

    int len = send(clientfd, buffer.c_str(), strlen(buffer.c_str()) + 1, 0);
    if (-1 == len)
    {
        cerr << "send loginout msg error -> " << buffer << endl;
    }
    else
    {
        //代表用户退出登录了
        isMainMenuRunning=false;
    }
}

//接收线程
void readTaskHandler(int clientfd)
{
    for ( ;; )
    {
        char buffer[1024] = {0};
        int len = recv(clientfd, buffer,1024,0);
        if (-1 == len||0 == len)
        {
            close(clientfd);
            exit(-1);
        }
        //接收Chaterver转发的数据，反序列化生成json数据对象
        json js = json::parse(buffer);
        int msgtype=js["msgid"].get<int>();
        if (ONE_CHAT_MSG == msgtype)
        {
            cout << js["time"].get<string>() << " [" << js["id"] << "]" << js["name"].get<string>()
            << " said: " << js["msg"].get<string>() << endl;
            continue;
        }
        if (GROUP_CHAT_MSG == msgtype)
        {
            cout << "群消息[" << js["groupid"] << "]:" << js["time"].get<string>() << " [" << js["id"] << "]" << js["name"].get<string>()
                 << " said: " << js["msg"].get<string>() << endl;
            continue;
        }

    }
}
